Ideal for drinking water applications, water supply from wells, water distribution applications
Capable of suction up to 8m
Determining whether the pump will be activated or deactivated according to the user's needs thanks to flow control
Max. fluid temperature 35 °C
Network connection 1~230 V,50 Hz
Protection / Insulation class IP44 / F
Max. suction height 8m
Setting pressure (on/off) 1/3 bar
| Model | A | B | C | D | TO | H | Weight (kg) |
|---|---|---|---|---|---|---|---|
| (mm) | |||||||
| Control SPG 3-45 | 250 | 145 | 185 | 196 | 145 | 353 | 16 |
| Control SPG 9-45 | 282 | 171 | 288 | 236 | 192 | 368 | 39 |
