Suitable for industrial use
20 l/min Capacity
WITHOUT CHIMNEY
Wired remote control
High Efficiency
High Capacity
Flame Modulation
Electronic Ignition
Adjustable Water Temperature
Compact Dimensions
6 Different Safety Systems
Fault Warning System
Freeze Protection
High Temperature Protection
Ability to work with natural gas or LPG
Ability to Work with Low Water Volume and Pressure
Environmentally Friendly Low NO Emission Burner
2 Years Standard Warranty Period
Widespread Service Network Throughout Türkiye
| Technical Specifications | |||
|---|---|---|---|
| Gas Type | - | Natural gas (G20) | LPG (G30) |
| Gas Inlet Pressure | mbar | 21 | 30 |
| Fan Power | Watts | 50 | 50 |
| Water Flow ΔT 20 °C | liters/min. | 25 | 25 |
| Water Flow ΔT 25 °C | liters/min. | 20 | 20 |
| Rated Load Q | kW | 39.75 | 39.75 |
| Rated Power P | kW | 35.1 | 35.1 |
| Min. Water Pressure | bar | 0.3 | 0.3 |
| Max. Water Pressure | bar | 10 | 10 |
| Electrical connection | - | 220-240 AC 50Hz IP 44 | 220-240 AC 50Hz IP 44 |
| Net Weight | kg | 20.5 | 20.5 |
| Gross weight | kg | 21.7 | 21.7 |
| Dimensions | mm | 391 x 197 x 583 | 391 x 197 x 583 |
| Cold Water Inlet | inch | 3/4 | 3/4 |
| Hot Water Outlet | inch | 3/4 | 3/4 |
| Gas Inlet | inch | 3/4 | 3/4 |
| .Waste Gas Channel | - | None | None |
| Fresh Air Duct | - | None | None |
